6-Port FE Micro Switch G6
MS450330M-G6+
MS450330M-G6+
MS450331M-G6+
MS450331M-G6+
MS450341M-G6+
MS450341M-G6+
MS450341M-G6+AL
MS450341M-G6+AL

6-Port FE Micro Switch G6

  • Smallest & most compact Gigabit Ethernet switch on the market in M45 design for tool-free installation in cable ducts, floor tanks etc.
  • 6-Port Full Gigabit Ethernet Switch
  • High security through SSH, HTTPS, SNMPv3, Port Security 802.1x and full RADIUS NAC compatibility
  • Internal power supply with 230VAC input
  • Intuitive management via Web, SSH, SNMP interface and MICROSENS NMP software
  • LWL uplink (100Base-FX) in SC or ST Multimode
  • always M45, whether high or transverse
  • MicroSD, Device Server Port?
Secure Download
Detail information
Description
Description

With the current 6th generation of Micro Switches (according to IEEE 802.3az Energy Efficient Ethernet) MICROSENS continues the device form of the installation switch available since 1995. Within the Fiber to the Office (FTTO) concept, the Micro Switch represents the decentralized workstation component for converting or switching the optical signal coming directly from the central building distributor to the typical RJ-45 user interface in the form of a fiber optic interface.

The Fast Ethernet version of the micro switch has a fiber optic uplink in 100Base-FX with either a fixed SC or ST optic and a further port hidden within the installation (also referred to by MICROSENS as a "downlink"). This downlink serves as an extension or hidden user port when the FTTO network is aligned in a star configuration in order to network further applications (WLAN access point in the double ceiling or similar) within the cabling infrastructure.

In the non-PoE Micro Switch version, the Micro Switch is powered directly via the existing 230 VAC networks. Within the installation, 4 TP ports 10/100/1000Base-T are always designed as user ports.

The hidden mini-USB interface serves as console port for direct management access to the high-performance Layer2 management, based on a future-oriented Linux operating system. The very wide range of features (especially in the area of IT security, IEEE 802.1x, VLANs IEEE 802.1q etc.) is shown in the firmware feature list (see download area), which is always extended by the implemented features after the firmware has been upgraded.

Access is password-protected via all common management interfaces such as browser-based (via web browser https/http), SSH, SNMPv3. MICROSENS NMP software optimizes access to a large number of micro switches within an FTTO network using group and master configuration.

The microSD card slot can optionally be used as a backup system for firmware and configuration. The complete device status can be transferred by exchanging the card. The memory card complies with the industry standard. A fault-tolerant journaling file system is used, which can be encrypted using the security option.

Products
Products
Products

MS450330M-G6+


Product is available

MS450330M-G6+

6-Port FE Micro Switch G6 1x 100FX ST/MM, horizontal, managed, 5x 10/100/1000T, 230VAC, microSD-Slot, RS-232 Port (mini USB)

5x RJ-45, 1x ST duplex MM, 1x 3plg. 230VAC, 1x Konsole, 1x microSD-Slot

Products

MS450331M-G6+


Product is available

MS450331M-G6+

6-Port FE Micro Switch G6 1x 100FX SC/MM, horizontal, managed, 5x 10/100/1000T, 230VAC, microSD-Slot, RS-232 Port (mini USB)

5x RJ-45, 1x SC duplex MM, 1x 3plg. 230VAC, 1x Konsole, 1x microSD-Slot

Products

MS450340M-G6+


Product is available

MS450340M-G6+

6-Port FE Micro Switch G6 1x 100FX ST/MM, vertikal, managed, 5x 10/100/1000T, 230VAC, microSD-Slot, RS-232 Port (mini USB)

5x RJ-45, 1x ST duplex MM, 1x 3plg. 230VAC, 1x Konsole, 1x microSD-Slot

Products

MS450341M-G6+


Product is available

MS450341M-G6+

6-Port FE Micro Switch G6 1x 100FX SC/MM, vertikal, managed, 5x 10/100/1000T, 230VAC, microSD-Slot, RS-232 Port (mini USB)

5x RJ-45, 1x SC duplex MM, 1x 3plg. 230VAC, 1x Konsole, 1x microSD-Slot

Accessories
Accessories

MS140894X-4G


Product is available

MS140894X-4G

Micro Storage Media Card 4GB für MICROSENS G6 Micro Switches, -25..+85°C

Accessories

MS140805-G6


Product is available

MS140805-G6

DIN-Rail Adapter für Micro Switch G6 drehbar, inkl. Schrauben

Accessories

MS190410-01,5


Product is available

MS190410-01,5

Konsolenkabel für G6 Micro Switch mit RS-232 Port (mini USB), auf SUBD9 weiblich, Länge 1,5m

Accessories

MS140800


Product is available

MS140800

Halter für Hutschiene Kunststoff schraubbar, schwarz

Accessories

MS190050


Product is available

MS190050

Abmantelwerkzeug für Rundkabel 4-16mm Ø Rund-/Längsschnitt
