Industrial Entry Line Fast Ethernet Switch PoE+

Industrial Entry Line Fast Ethernet Switch PoE+

Industrial Entry Line Fast Ethernet Switch PoE+

  • Cost-effective Plug and Play Fast Ethernet and PoE+ performance for industrial environments with DIN rail adapter and extended operating temperature range -40°..+75°C
  • All 4 TP ports with Power-over-Ethernet + (802.3at)
  • Many different versions with TP or fiber optic uplink in SC/ST in multimode or single mode
  • Dual DC-Inputs 48..56 VDC
  • Potential-free relay contact
  • Robust metal housing with IP-30 protection class
Download
Secure Download
Detail information
Description
Description

The Entry-Line series stands for economical and powerful Plug and Play Industrial Ethernet solutions. It offers a wide range of devices with diverse features. The Entry Line Fast Ethernet Switches PoE+ product series consists of the switches with different network interfaces:

- 5-Port Fast Ethernet Switch (4x 10/100Base-TX PoE+, 1x 10/100Base-TX)

- 5-Port Fast Ethernet Switch (4x 10/100Base-TX PoE+, 1x 100Base-FX Multimode SC)

- 5-Port Fast Ethernet Switch (4x 10/100Base-TX PoE+, 1x 100Base-FX Single Mode SC)



The maximum power budget available for the provision of PoE+ ports (according to IEEE 802.3af/at) makes the devices powerful network distributors and suppliers, the use of full PoE+ performance is possible with these switches.

Whether video surveillance, security technology, IP-based intercom or WiFi access points - more and more end devices require ever higher power supply. Entry line switches with PoE+ optimally meet these increased requirements. The four 10/100Base-TX ports can supply end devices with up to 30 W per port.

Three power supply inputs enable redundant power supply to the switches and connected devices. If the voltage of the primary or secondary supply fails, an alarm can be triggered. The robust metal housing with DIN-Rail adapter (as well as alternative wall mounting adapters included) and the extended operating temperature range from -40° to +75°C are further features of the Entry Line series.

Products
Products
Products

MS657100PX


Product is available

MS657100PX

5-Port FE Industrial Entry Line Switch PoE+ 5x 10/100TX, 4x PoE+, DIN-Rail, -40..+75°C, 48..56VDC, 1x RC

5x RJ-45, 2x 2plg. 48..56VDC, 1x DIN-Conn., 1x RC

Products

MS657102PX


Product is available

MS657102PX

5-Port FE Industrial Entry Line Switch PoE+ 1x 100FX SC/MM, 4x 10/100TX PoE+, DIN-Rail, -40..+75°C, 48..56VDC, 1x RC

4x RJ-45, 1x SC duplex MM, 2x 2plg. 48..56VDC, 1x DIN-Conn., 1x RC

Products

MS657104PX


Product is available

MS657104PX

5-Port FE Industrial Entry Line Switch PoE+ 1x 100FX SC/SM, 4x 10/100TX PoE+, DIN-Rail, -40..+75°C, 48..56VDC, 1x RC

4x RJ-45, 1x SC duplex SM, 2x 2plg. 48..56VDC, 1x DIN-Conn., 1x RC

End of Life / Out of product range
End of Life / Out of product range

MS655100PX-48

show alternative

Product reached his Life-Time

MS655100PX-48

End of Life / Out of product range

5 Port Fast Ethernet Industrial PoE Switch 5x10/100Base-TX, 4x PoE PSE

EOL -> MS657100PX

hide alternative

MS657100PX

hide alternative

Product is available

MS657100PX

hide alternative

5-Port FE Industrial Entry Line Switch PoE+ 5x 10/100TX, 4x PoE+, DIN-Rail, -40..+75°C, 48..56VDC, 1x RC

5x RJ-45, 2x 2plg. 48..56VDC, 1x DIN-Conn., 1x RC

End of Life / Out of product range

MS655102PX-48

show alternative

Product reached his Life-Time

MS655102PX-48

End of Life / Out of product range

5 Port Industrial PoE Switch FO UplinkSC 4x10/100BaseTX 1x100BaseFX 1310nm MM SC extended temperature range -40..+75°C

EOL -> MS657102PX

hide alternative

MS657102PX

hide alternative

Product is available

MS657102PX

hide alternative

5-Port FE Industrial Entry Line Switch PoE+ 1x 100FX SC/MM, 4x 10/100TX PoE+, DIN-Rail, -40..+75°C, 48..56VDC, 1x RC

4x RJ-45, 1x SC duplex MM, 2x 2plg. 48..56VDC, 1x DIN-Conn., 1x RC

End of Life / Out of product range

MS655104PX-48

show alternative

Product reached his Life-Time

MS655104PX-48

End of Life / Out of product range

5 Port Industrial PoE Switch FO UplinkSC 4x10/100TX 1x100FX 1310nm SM 30km SC

EOL -> MS657104PX

hide alternative

MS657104PX

hide alternative

Product is available

MS657104PX

hide alternative

5-Port FE Industrial Entry Line Switch PoE+ 1x 100FX SC/SM, 4x 10/100TX PoE+, DIN-Rail, -40..+75°C, 48..56VDC, 1x RC

4x RJ-45, 1x SC duplex SM, 2x 2plg. 48..56VDC, 1x DIN-Conn., 1x RC
