MSP3000 Filter modules (R)OADM/Mux

MSP3000 Filter modules (R)OADM/Mux

MSP3000 Filter modules (R)OADM/Mux

  • Complete ROADM unit for 10 directions available in one height unit
  • ROADM solutions support colourless, directionless, contentionless and gridless (CDCG) system configurations
  • Extension of the ROADM configuration without influencing the active traffic
  • Automatic adjustment of power per channel for optimum OSNR ratio
  • Filter modules available for the extended operating temperature range (-45°... + 65°C)
Informations détaillées
Description
Description

MICROSENS offers a very extensive product family of filter modules,which completely covers the essential market requirements.



Pluggable Modules

This segment consists of the classic CWDM/DWDM multiplexers that are plugged into the respective slots of the chassis (pluggable modules).

Rack Mounted Modules

The classic type of CWDM/DWDM multiplexer is also available in a 19" 1U rack mount version (Rack Mounted Modules). The product range includes a 16 channel DWDM filter with upgrade port, which can be upgraded to a 32 channel filter and a 40 channel filter. This 40-channel filter can also be equipped with an upgrade channel so that an 80-channel filter can be configured via event and odd channels.

Optical Add/Drop Modules

Also called add/drop multiplexers, these ensure that the optical network can be kept flexible by coupling and uncoupling any optical channels. These add/drop modules in cassette form can be plugged into a 19" 1U housing, whereby the 1U housing can accommodate a total of 4 cassettes. These cassette-shaped filters are also suitable for the extended temperature range from -40 to +65°C and are also available in a version for single fiber applications. For the Add/Drop filters, the parameters 1, 2 or 4 channel Add/Drop filters apply, either in one direction (single sided) or in two directions (dual sided).

In addition to the add/drop filters, DWDM and CWDM multiplexers are also available in cassette form. In the DWDM area, these are 8 channel filters that can be upgraded, so that a total of 32 channels can be provided in a 1U housing with 4 cassettes. In the CWDM range, cassettes with 10 wavelengths and 8 wavelengths are available.. These can achieve a total of 18 CWDM wavelengths.

Reconfigurable Optical Add/Drop Multiplexer (ROADM)

A ROADM is a special form of add/drop multiplexer that has the capability of remotely switching the data traffic of a WDM system at the wavelength level. This makes it possible to remotely couple and uncouple individual channels without the need for optical-electronic-optical conversion.

The latest ROADM technology from MICROSENS is based on 19" 1U boxes and is used as a ROADM unit in a ROADM network. There are 2 versions for a total of 4 directions (4 Degree) and 10 directions (10 Degree) available. Each ROADM contains the Wave Selective Switch (WSS), corresponding amplifiers and an optical channel monitor. The functionalities provided by these latest generation ROADM systems are Colorless, Directionless, Contentionless and Gridless (CDCG).



Produits
Produits
Products

MS430731M


Le produit est disponible

MS430731M

Optical Passive Rack, 1HU, 4 Cartridges capacity, Extended Temperature Range (-40 to 65°C)

Products

MS430720B


Le produit est disponible

MS430720B

4 Channel optical MUX/DMUX Unit (ch 45-47-49-51)

Products

MS430720BR


Le produit est disponible

MS430720BR

4 Channel Blue Band MUX Unit (ch 45-47-49-51) /Red Band DMUX (ch 30-32-34-36)

Products

MS430720R


Le produit est disponible

MS430720R

4 Channel optical MUX/DMUX Unit (ch 30-32-34-36)

Products

MS430720RB


Le produit est disponible

MS430720RB

4 Channel Red Band MUX Unit (ch 30-32-34-36) / Blue Band DMUX (ch 45-47-49-51)

Products

MS430738M-C1X


Le produit est disponible

MS430738M-C1X

8 Channel CWDM (1271-1371nm & 1431-1451nm) Mux /Dmux with upgrade port, Extended Temperature Range (-40 to 65°C)

Products

MS430738M-C2X


Le produit est disponible

MS430738M-C2X

8 Channel CWDM (1471-1611nm) Mux /Dmux , with Monitoring Taps, Extended Temperature Range (-40 to 65°C)

Products

MS430740-C1X


Le produit est disponible

MS430740-C1X

10 Channels CWDM Mux (1271-1451nm) Mux /Dmux with upgrade port ,  Extended Temperature Range (-40 to 65°C)

Products

MS430742MX


Le produit est disponible

MS430742MX

2 Channel single sided CWDM OADM "Add/Drop to/from Line", dual sided, ETR (-40 to 65°C)
